Temperature/Humidity datalogger with docking station and PC software

The 42275 is a Temperature/Humidity Datalogger Kit with PC Interface. This waterproof (IP65) datalogger records up to 16,000 readings (8,000 readings for each parameter) with a date/time stamp that can be downloaded to your PC for analysis. Temperature/Humidity can be viewed on the datalogger's LCD display. Data can be downloaded from a docking station, which can add additional loggers. Programmable sampling rate from 1sec to 2hrs plus Hi/Lo limits with alarm indication. Product comes complete with docking station, software, and one 42270 datalogger with Li-Ion battery.

• Wide operating temperature range: -40°F to 185°F (-40°C to 85°C)
• Humidity range: 0 to 100% RH
• Records up to 16,000 readings (8,000 readings for each parameter)
• Use in storage containers, shipping vans, freezers and more
• Logs data for days, weeks or months - up to 1 year battery life
• Multiple 42270 dataloggers can be programmed and data downloaded from one single docking station
• Programmable sampling rate from 1sec to 12hrs plus Hi/Lo limits with alarm indication
• Program the logger, analyze and store data using Windows^®compatible software
• View current temperature/humidity on Datalogger's LCD display
• Three start methods: Scheduled, immediate or magnetic
• Includes USB docking station with cable, 42270 Humidity/Temperature datalogger and PC software

Specifications                                            Range
Temperature                                     -40°F to 185°F (-40°C to 85°C)
Humidity                                             0 to 100%RH
Datalogging Interval                        1 sec to 12 hours
Memory                                              42260/42265: Temperature: 8000 points; 42270/42275: Temperature: 8000 points and Relative Humidity: 8000 points
Dimensions                                        42260 or 42270: 3 x 2.3 x 0.88" (76 x 57.2 x 22.3mm); 42265 or 42275:4.9 x 3.8 x 2” (123.8 x 95.3 x 51mm)
Weight                                                42260 or 42270: 2.6oz. (72.6g), 42265 or 42275: 9oz (254g)
